- Two piece wing
- Functional Flaps
- Made of highly durable EPO
- Fold away high efficiency propeller
- Snap together assembly, no glue necessary
Overview
True to the FMS spirit, no detail was overlooked in the design of the ASW-17. The FMS engineers made 4 expensive tooling adjustments just to micro-adjust the airfoil for perfect efficiency. The wing, vertical and horizontal stabilizers are designed with a snap-together structure. With a simple snap, the surfaces attach to the fuselage with pinpoint precision- no screws or glue necessary! Build the aircraft in as little as 3 minutes! Like the 3000mm Fox, the ASW-17 has a pre-installed carbon fiber spar that ensures wing rigidity in high-G maneuvers. To achieve the same dihedral as the real aircraft, the ASW-17 was designed with a specialized CNC aluminum spar joiner- allowing the aircraft to maintain its wing geometry during demanding flight routines. Performance-wise, a high-quality Hobbywing 40A ESC paired with a Predator 3541-750KV motor provides ample power with a 4S pack to perform most aerobatic maneuvers. If efficiency, stability and aerobatic capabilities are what you seek in a glider, look no further than the FMS 2500mm ASW-17!
Needed to Complete
- 14.8V 2200-2600mAh 35C Battery
- 6-Channel Radio
What's in the Box?
- (1) ASW-17 EP Glider PNP
- (1) Hobbywing 40A ESC
- (1) Predator 3541-750KV motor
- (1) Product Manual
Build the aircraft in minutes!
The wing, vertical and horizontal stabilizers are designed with a snap-together structure. With a simple snap, the surfaces attach to the fuselage with pinpoint precision. No screws or glue necessary!
High strength wing structure
Like the 300mm Fox, the ASW-17 has a pre-installed Carbon-fiber spar that ensures wing rigidity in high-G maneuvers.
Metal spar connectors
Metal spar connectors embedded within the wing ensures scale and functional wing dihedral.
Spar joiner
The ASW-17 was designed with specialized CNC aluminum spar joiner — allowing the aircraft to maintain its wing geometry during demanding flight routines.
Aileron and Flap Structure
Reinforced aileron and flap structure for precision flight characteristics.
Latch and Canopy
Press-to-release canopy latch and a textured canopy.
Motor, ESC and Servo
Predator 3541-750KV motor, a high-quality Hobbywing 40A ESc and 17g servos.
Product Specifications
| Approximate Assembly Time | Less than 1 Hour |
| Approximate Flight Time | 10 minutes |
| CG (Center of Gravity) | 2.7 - 3.1" (70 - 80mm) back from leading edge of wing measured at the fuselage |
| Charger | Sold Separately |
| Completion Level | Plug-N-Play |
| Flaps | Yes |
| Power Type | Electric |
| Landing Gear | Monowheel with tail skid |
| Material | EPO |
| Minimum Required Radio | 6-channel |
| Minimum Speed Control | 40A included with XT-60 battery connector |
| Motor Size | 3541-750Kv |
| Product Length | 54.7 in (139mm) |
| Propeller Size | 13.5x6 fold away |
| Recommended Motor Battery | 4S LiPo 14.8V 35C 2200-2600mAh w/XT60 connector (sold separately) |
| Technology | AS3X |
| Transmitter Range | Full |
| Trim Scheme Colors | White with black lettering |
| Wing Area | 779.5 sq in (50.3 sq dm) |
| Wing Loading | 0.09 oz sq/in (45.7 g sq/dm) |
| Wingspan | 98.4 in (2500mm) |
