A6190 Standard Metal Gear HV Digital Servo

The Spektrum A6190 Metal Gear High Voltage Digital servo offers impressive performance for pilots looking for an excellent value standard size servo for their Sport and Trainer aircraft. High voltage capable, the A6190 can produce 8.3kg-cm (115 in-oz) of torque at 0.17 sec/60° speeds with 8.4V input. Its low-wear, metal gear drive train is powered by a 5-pole ferrite motor and is supported by dual ball bearings for smooth operation. It also features low deadband and precise position control. Like all Spektrum servos, the A6190 delivers reliability, consistency and performance that are second to none.

  • High Voltage (HV) capable (4.8-8.4v input range)
  • Perfectly suited for sport and trainer type model aircraft requiring standard size servos
  • Low wear and tightly meshed all metal gear train
  • Dual bearing supported drive train helps maximize smooth operation
  • Operating Frequency: 200hz to 333hz

Features

  • High Voltage (HV) capable (4.8-8.4v input range)
  • Perfectly suited for sport and trainer type model aircraft requiring standard size servos
  • Excellent performance and value for its class (8.3kg-cm and .17 sec/60° @8.4v)
  • Low wear and tightly meshed all metal gear train
  • Dual bearing supported drive train helps maximize smooth operation
  • Operating Frequency: 200hz to 333hz

Product Specs

Servo Operating Voltage
4.8 - 8.4V (HV)
Product Width
0.78" (20 mm)
Application
Airplane
Overload Protection
No
Product Weight
1.9 oz (54g)
Spline Count
23 - Tooth
Water-Resistant
No
Material
Plastic
Programmable
No
Prop 65
Prop 65 Warning Icon  California Residents Prop 65 WARNINGS.
Servo Size Category
Standard
Product Length
1.47" (37 mm)
Maximum Servo Speed
0.22 sec/60 deg @ 6.0V; 0.17 sec/60 deg @ 7.4V; 0.13 sec/60 deg @ 8.4V
Deadband
<1µs
Input Voltage
4.8V-8.4V
Product Application
Air
Product Height
1.58" (40 mm)
Servo Type
Digital
Bearing
Dual BB
Bushing Or Bearing
Bearing
Gear Type
Metal
Connector Type
Universal
Maximum Servo Torque
90 oz-in (6.48kg-cm) @ 6.0V; 98 oz-in (7kg-cm) @ 7.4V; 115 oz-in (8.3kg-cm) @ 8.4V

Compatibility

No results for your given fitment filters

FAQ

The servo works between 4.8V to 8.4V input, so you have a wide range of power options. The Capacity of the battery will depend on how many servos you have in the plane and expected flight time, plus some reserve to be safe. As it is a HV servo, best speed and torque will be attained using a 2S LiPo battery pack.

Product Details

icon-box
In The Box
  • (1) A6190 Standard Digital Servo
  • (4) Pre-installed Mounting Grommets And Eyelets With Hardware
  • (3) Plastic Servo Arms and (1) Screw
