Join us at RC Fest June 9 - 10!
Learn More
In Stock
1/10 R/C VQS (2020)
Item No.
Tamiya -
TAM58686A
$371.00
In Stock
1/10 R/C VQS (2020)
Item No.
Tamiya -
TAM58686A
$371.00
The Vanquish is a legendary buggy from our R/C back catalog. It’s now available again in the form of a re-issue assembly kit renamed the VQS. The kit receives tweaks to the original to bring it into the modern age of R/C fun! We have also saved builders some work too, with a pre-cut and pre-painted body!
- Lightweight And Durable Polycarbonate, Pre-Painted Body
- Body Stickers Are Based Upon Those In The Original Release
- ABS Plastic Monocoque Bathtub Chassis
- Aluminum Front Uprights And Efficient Universal Shafts
- Planetary Gear Differential Units From The Original Avante
Complete your product
This product may require additional items in order to work out of the box. See below for required items that may be needed to complete.
I do not need to purchase this item.
TAM58686A
DX3 Smart 3-Channel Transmitter with SR315 Receiver
SPM2340
In Stock
$99.99
TAM58686A
DX5C Smart 5-Channel Transmitter Combo with SR315 Receiver
SPM5115C
In Stock
$184.99
TAM58686A
SLT3 3-Channel Transmitter with SR315 Receiver
SPMSLT300
In Stock
$79.99
TAM58686A
TTX300 3-Channel SLT Transmitter with TR325 Micro Receiver
TACJ0300
In Stock
$39.99
Price reduced from
$74.99
to
TAM58686A
DX5 Pro 5-Channel DSMR Transmitter with SR2100 Receiver
SPM5025
In Stock
$399.99
TAM58686A
DX5C Smart 5-Channel DSMR Transmitter with SR6100AT Receiver
SPM5120
In Stock
$219.99
TAM58686A
DX5 Rugged 5-Channel DSMR Transmitter with SR515
SPM5200
In Stock
$279.99
TAM58686A
SLT3 3-Channel SLT Transmitter with SLR300 Receiver
SPMSLT350
In Stock
$64.99
I do not need to purchase this item.
TAM58686A
Speedpack2 7.2V 2400mAh 6C NiMH, Flat Tamiya
DYNB2060
In Stock
$20.99
TAM58686A
Speedpack2 7.2V 3300mAh 6C NiMH, Flat Tamiya
DYNB2070
In Stock
$28.99
TAM58686A
7.4V 3300mAh 2S 30C Reedy WolfPack LiPo Battery: T-Plug
ASC751
In Stock
$49.49
TAM58686A
7.4V 4000mAh 2S 35C Reedy WolfPack LiPo Battery: T-Plug
ASC752
Next Shipment June 2023
$64.79
TAM58686A
Speedpack2 7.2V 1800mAh 6C NiMH, Flat Tamiya
DYNB2050
In Stock
$16.99
TAM58686A
7.2V 3300mAh 6-Cell Speedpack2 Flat NiMH Battery: EC3
DYNB2070EC
In Stock
$28.99
TAM58686A
Speedpack2 7.2V 5100mAh 6C NiMH, Flat Tamiya
DYNB2090
In Stock
$45.99
TAM58686A
7.2V 5100mAh 6-Cell Speedpack2 Flat NiMH Battery: EC3
DYNB2090EC
In Stock
$45.99
TAM58686A
7.4V 4000mAh, 2S 60C LiPo, Deans
GEA40002S60D8
Next Shipment June 2023
$35.99
TAM58686A
7.2V 2200mAh, NiMH, Tamiya Plug
GEANM6S2200T
In Stock
$19.99
TAM58686A
7.2V 3000mAh, NiMH, Tamiya Plug
GEANM6S3000T
Next Shipment June 2023
$25.99
TAM58686A
7.2V 4200mAh 6-Cell Sub-C Stick NiMH Battery: Tamiya Connector
ONXP5428
Next Shipment June 2023
$34.99
TAM58686A
2400mAh 6-Cell 7.2V Smart NiMH Battery IC3
SPMX24006C3
In Stock
$28.99
0
of 1 Selected
I do not need to purchase this item.
TAM58686A
Prophet Sport Mini 50W Multichemistry Charger
DYNC2030
In Stock
$34.99
TAM58686A
Reedy 324-S Compact Balance Charger
ASC27201
Next Shipment June 2023
$35.99
TAM58686A
Reedy 1416-C2L Dual AC/DC Comp Balance Charger
ASC27203
In Stock
$187.99
TAM58686A
Passport P2 100W AC/DC 2-Port Multicharger with Bluetooth Connectivity
DYNC3016
In Stock
$149.99
TAM58686A
Imars III PRO 10A Smart Balance RC Battery Charger
GEA100WMPRO
In Stock
$59.99
TAM58686A
RDX1 Mini AC Charger
HRC44295
In Stock
$46.99
TAM58686A
RDX2 Mini AC Balance Charger
HRC44299
In Stock
$84.99
TAM58686A
S1500 DC Smart Charger, 1x500W
SPMXC1050
In Stock
$129.99
TAM58686A
S155 G2 1x55W AC Smart Charger
SPMXC2050
In Stock
$59.99
0
of 1 Selected
I do not need to purchase this item.
TAM58686A
S6020 Standard Digital High Torque Metal Gear Surface Servo
SPMSS6020
In Stock
$37.99
TAM58686A
RT1705A Digital HV Aluminum Brushless Low-Profile Servo
ASC27119
In Stock
$223.19
TAM58686A
HS-77BB Standard Analog Low Profile Servo
HRC31077S
In Stock
$29.99
TAM58686A
HS-645MG High Torque Metal Gear Premium Sport Servo
HRC32645S
In Stock
$34.99
TAM58686A
HS-5565MH Standard Digital HV High Speed Metal Gear Servo
HRC35565S
In Stock
$72.99
TAM58686A
D485HW Standard Digital Wide Voltage Karbonite Gear Servo
HRC36485
In Stock
$28.99
TAM58686A
D625MW Standard Digital High Speed Metal Gear Servo
HRC36625
In Stock
$39.99
TAM58686A
D645MW Standard Digital High Torque Metal Gear Servo
HRC36645
In Stock
$43.99
TAM58686A
DB778WP Ultra Torque Brushless Low Profile Waterproof Surface Servo
HRC36788S
In Stock
$125.99
TAM58686A
S6170 Standard Digital Surface Servo
SPMSS6170
In Stock
$31.99
TAM58686A
S6240 Standard Digital High Speed Waterproof Metal Gear Surface Servo
SPMSS6240
In Stock
$89.99
TAM58686A
T360 Standard Digital HV High Speed Metal Gear Servo
TEKTT1506
In Stock
$169.99
0
of 1 Selected
I do not need to purchase this item.
TAM58686A
Tazer Twin 2S Brushless Motor/ESC Combo, 3000Kv: 1/10 2WD
DYNS1450
In Stock
$99.99
TAM58686A
1/10 Mamba X SCT Pro Waterproof ESC/1410-3800Kv Sensored Brushless Motor Combo: 4mm Bullet
CSE010016100
In Stock
$249.95
TAM58686A
Copperhead 10 1410-3800Kv Motor/ESC Combo, Special Edition
CSE010017001
Next Shipment June 2023
$184.95
TAM58686A
Tazer 1/10 6-Pole Waterproof ESC/Brushless Motor Combo V2, 3300Kv: 3.5mm Bullet, EC3
DYNS0600
Not Available
$109.99
TAM58686A
Firma 85A Brushless Smart ESC / 4000Kv Sensorless Motor Combo
SPMXSEMC02
In Stock
$104.99
0
of 1 Selected
1/10 R/C VQS (2020)
Item No.
Tamiya -
TAM58686A
Product
$371.00
Add Ons
Estimated Total:
$371.00
Earn points on this item
ⓘ
Selected Store
Product Details
In The Box
- (1) 1/10 R/C VQS Kit
- (1) TBLE-02S ESC
- (1) 540-Size Brushed Motor
- (1) Instruction Manual
Needed to Complete
- (1) 2+ Channel Radio System
- (1) Standard-Size Steering Servo
- (1) 7.2V - 7.4V Battery
- (1) Battery Charger
Quick Links
Features
- Lightweight and durable polycarbonate, pre-painted and cut, with body mount holes already pre-drilled.
- Body stickers are based upon those in the original release, and just require application to complete the body.
- ABS plastic monocoque bathtub chassis.
- Aluminum front uprights and efficient universal shafts are designs inherited from the 2011 re-issue of the Avante.
- Planetary gear differential units from the original Avante.
- Includes 540-Size brushed motor and Tamiya TBLE-02S ESC, capable of running sensored brushless motors and brushed motors alike.
Capable Off-Road Chassis
This R/C model assembly kit is an updated re-release version of a 1988 buggy from the Tamiya back catalog, which inherited its make-up from the legendary race-oriented Avante. The forward cockpit body design - and the rear wing - are molded in lightweight polycarbonate and pre-painted black, pre-cut with body mount holes pre-made to save on some preparation work. An ABS plastic monocoque frame is employed, with responsive shaft-driven 4WD plus a triple differential setup, four-wheel double wishbone suspension and plenty more - superb off-road driving awaits!
This model's durable ABS plastic monocoque frame protects vital R/C equipment and boosts suspension performance with its excellent rigidity. A total of three differentials are employed: small front and rear planetary gear differentials, and a center differential with ball thrust bearing; front and rear gearboxes also have maintenance hatches. Universal shafts front and rear ensure smooth, efficient drive and minimal worry about parts coming loose due to bumps and shocks, while the Avante-based 4-wheel double wishbone suspension employs plastic lower arms with threaded shaft upper arms that allow swift adjustment of camber. Front uprights are aluminum, and stabilizers are included for the front and rear.
Video Overview
Video Overview
Front Suspension
The front double wishbone suspension employs aluminum uprights, while universal drive shafts are used front and rear.
Tie Rod Setup
Three-piece steering tie rod setup. The center plate is crafted in 2mm carbon fiber.
Shaft-driven 4WD
Reponsive shaft-driven 4WD is powered by a longitudinally-placed motor, with a ball differential in the drive gear.
Gear Box
Sealed gearboxes front and rear house compact planetary gear differentials which utilize the Avante design.
Rear Suspension
The rear suspension setup features long, ball-mounted lower arms. Threaded upper arms (front and rear) allow adjustment of camber.
Bathtub Frame
The monocoque bathtub frame is a lightweight, durable design that protects and allows easy access to R/C equipment.
Battery Compartment
Battery changes are made from the underside. The model is compatible with Tamiya 7.2V Racing Pack and LF2200-6.6V battery packs.
Tires and Wheels
Lightweight 6-spoke wheels are paired with pin spike tires. Front wheels are narrow, and rear wheels are wide designs.
Product Specifications
| Body | Polycarbonate |
| Scale | 1/10 |
| Charger | Sold Separately |
| Motor Type | Brushed |
| Speed Control | Included |
| Wheelbase | 10.82" (275 mm) |
| Product Width | 9.25" (235 mm) |
| Radio | Sold Separately |
| Power Type | Electric |
| Vehicle Type | Buggy |
| Chassis | ABS Plastic |
| Completion Level | Kit |
| Drivetrain | 4WD |
| Product Height | 5.9" (150 mm) |
| Battery | Sold Separately |
| Motor Size | 540 |
| Product Length | 17.12" (435 mm) |
| Suspension | Fully Independent Double Wishbone |
| Ball Bearings | Includes full ball bearings |
