1/10 22S 2WD SCT Brushless RTR with AVC
Item No.
LOS03013
Discontinued
1/10 22S 2WD SCT Brushless RTR with AVC
Item No.
LOS03013
Selected Store
Product Details
Quick Links
Manuals & Support
Key Features
- All New Race-inspired 2WD Platform
- AVC® (Active Vehicle Control®)
- Dynamite® Fuze™ Sport ESC
- Team Losi Racing® Option Part Upgrades Available
- Bottom Loading Battery
- All Metal Gear Transmission
- Gear Differential
- Spektrum™ Servo
- Spektrum™ Dx2e Active Radio System
- Race-Inspired Licensed Scale Body
- MAXXIS Razr MT Tires
- 12mm Race-Inspired Shock Absorbers
Overview
Based on the Team Losi Racing® 22™ race platform, the all-new Losi® 22S SCT RTR has taken the performance and durability of the 22 platform and maximized it to become the ultimate Ready-to-Run performance. The 22 platform is a legend in the radio control racing world and this new Losi version is ready-made for racing while keeping the appeal of backyard bashing. A powerful Dynamite® brushless system provides abundant power that’s completely manageable with the aid of AVC® (Active Vehicle Control®) technology. The get-up-and-go of the 22S is easily handled by the race-inspired suspension of the championship winning 22 race platform. Several Team Losi Racing 22 platform performance parts can upgrade the look, style and performance of the 22S RTR. With user-friendly design concepts, like a bottom loading battery compartment and hard mounted electronics, the user experience is hassle-free allowing the bashing to begin right away.
Needed to Complete
- 2S or 3S LiPo Battery with EC3 Connector
- Suitable Battery Charger
What's in the box?
- (1) 1/10 22S™ 2WD SCT Brushless RTR with AVC
- (1) Spektrum DX2E ACTIVE 2-Channel DSMR Transmitter with SR310
- (1) Spektrum SRS6000 6-Channel DSMR AVC Surface Receiver
- (1) Spektrum 9KG 23T Waterproof Servo
- (1) Dynamite 3300Kv Fuze Brushless Motor
- (1) Dynamite 60A Fuze Brushless ESC
- (1) User Manual
Video Overview
Race Inspired 2WD Platform
Based on the legendary, high-performance 22 platform, the 22S SCT features a super-tough composite chassis and the ability to adjust the suspension and drivetrain for any condition.
Aluminum Front/Rear Chassis Plates
The 22S isn’t just a looker, it's built tough and tunable with aluminium chassis plates in the front and rear to provide chassis rigidity and extreme performance.
Quick Change Bottom Loading Battery Tray
With the turn of a dial you can unlock the bottom loading battery tray and quickly change batteries without the need to remove the body or hassle with body clips.
Dynamite Fuze 60A 3S ESC
The 60A ESC helps propel the 22S SCT to speeds in excess of 50mph. Pre-wired EC3 connector and 3S lipo compatibility, the 60A ESC represents the ultimate in performance and reliability.
Extreme Dynamite Fuze Power System For Speeds of 50+ MPH
The brushless ESC and motor provide wicked power with a 2 or 3 cell Li-Po (not included) that will blaze speeds of 50+ MPH on 3S power.
Hard Mounted Electronics
The Dynamite and Spektrum electronics are hard mounted to provide a clean look and to remain attached to the chassis even when pushing the 22S to it’s limits.
All Metal Gear Transmission
The 22S SCT comes with a metal gear transmission for bullet-proof reliability to withstand anything you throw at it, in your backyard or at the track.
Adjustable Oil Filled Differential
The oil filled differential helps the 22S handle like it’s on rails thanks to increased traction in all driving conditions. Unlike other SCT’s in this class, the rear differential can be tuned to perform like a beast in the backyard or at the track.
Dual Pad Slipper Clutch
Designed to not only be tough, but increase performance and withstand the extreme power from the included Dynamite Fuze brushless power system.
Race Inspired, Performance Suspension Package
Adjustable oil filled coil-over shocks on all four corners soak up the gnarliest terrain. The 12mm shocks are fully-adjustable and allow you to tune the handling of the 22S SCT to maximize performance and dominate anywhere.
Off-Road Style Wheel and Maxxis Razr MT Tire
Designed for maximum traction, the 22S SCT’s Maxxis Razr MT tires have enough bite to rip up the turns like a pro on the track as well as in the backyard.
12mm Wheel Hex
The 22S SCT comes standard with 12mm wheel hex which allow you to run aftermarket short course wheels with the same wheel off-set.
Spektrum Waterproof Servo
For added precision, the waterproof steering servo makes short work of tight turns. Drivers can crank it knowing the responsiveness is second to none.
Sealed Ball Bearings Throughout
Not only do sealed bearings improve your performance, they will allow you to run the 22S SCT in any condition without fear of drive train damage.
Full Metric Hardware
Complete metric hardware is featured throughout the 22S SCT, including bearings, screws and nuts.
Precision Driving With AVC® Traction Control
The receiver's built-in AVC (Active Vehicle Control) system works behind the scenes, making hundreds of throttle and steering adjustments per second, so more of the motor's power is translated into ballistic speed and acceleration instead of just flying dirt. Like traction control in your full-scale vehicle, you can activate or deactivate the system on the fly and adjust the level of stability based on driving conditions.
Spektrum DX2E Active Radio System
The Spektrum™ DX2e Active™ radio system offers advanced features like AVC control, a 3-position throttle limiting switch and travel adjust. It also has an expansion port that lets you add the Spektrum Speedometer or a Bluetooth module and phone mount to utilize the Spektrum Dashboard app.
Performance Add-Ons
Spektrum FPV Mount
Adding the included Spektrum FPV mount lets you easily install an all-in-one FPV (First Person View) system. When combined with the Spektrum heavy-duty FPV camera (SPMVA2510) and a headset (SPMVM430C), you’re ready to experience a driving sensation more intense than any other vantage point can offer.
Speedometer Add-On
Adding the optional Spektrum™ Speedometer allows you to instantly see your vehicle's speed in real time (other items may be required). It also records top speed and features an easy-to-read LED screen.
Spektrum Dashboard Mobile App
The Spektrum Dashboard Mobile application allows you to view everything from speed, motor or engine temperature, battery voltage and more (optional accessories required).
Product Specifications
Specs
| Ball Bearings | Full Ball Bearing |
| Battery | Sold Separately |
| Body | Polycarbonate, Screen Printed, 1.2mm |
| Brakes | Electronic |
| Charger | Sold Separately |
| Chassis | Molded composite |
| Completion Level | Ready-To-Run |
| Differential | Sealed Gear Differential |
| Drivetrain | 2WD |
| Front Track | 9.6 in (245mm) |
| Power Type | Electric |
| Gear Pitch | 48-Pitch |
| Ground Clearance | 2.1 in (53mm) |
| Internal Gear Ratio | 2.43:1 |
| Motor Size | 540 |
| Outer Diameter | 4.5 in (115mm) |
| Product Height | 7.8 in (198mm) |
| Product Length | 21.6 in (549mm) |
| Product Width | 11.7 in (296mm) |
| Radio | Included |
| Rear Track | 9.6 in (245mm) |
| Receiver | Included |
| Scale | 1/10 |
| Servos | Included |
| Shock Type | Oil-filled with Coil-Over Spring |
| Speed Control | Included |
| Spur Gear | 84T |
| Suspension | Lower A-Arm, Upper Link |
| Tire Tread | Razr |
| Vehicle Type | Short Course Truck |
| Wheelbase | 13.2 in (335mm) |
| Wheel Type | Losi SCT |
