This item is no longer available. Updated or related products shown below:
The Spektrum Team has been investigating sporadic reports from DSMX transmitter owners using their products in DSM2 mode. We have discovered that in some rare instances, DSMX equipped transmitters with the Product ID (PID) within this bulletin, may have a backwards compatibility issue that could cause a "hold" with the following superseded DSM2 receivers: AR500, AR6100, AR6100E, AR6110, AR6110E, AR6200 and AR6300. Note: This bulletin does not apply to DSM2 only transmitters.If you have a DSMX transmitter with one of the following PIDs, please complete the Transmitter Service Request Form to receive a prepaid shipping label to send your transmitter to Horizon Hobby for a free firmware update.
The PID is located in the battery compartment of your transmitter.
Transmitters with affected PIDs may be found in the following products: Blade mCP X RTF (BLH3500), E-flite Apprentice 15e RTF (EFL2725), Hangar 9 Alpha 40 DSM2 RTF (HAN4400) ,Hangar 9 P-51 Mustang MkII PTS RTF (HAN4425), Hobbyzone Super Cub DSM RTF (HBZ7400), ParkZone Radian RTF (PKZ4700), ParkZone P-51D BL DSM RTF (PKZ2200), ParkZone F4U Corsair RTF (PKZ4600), Phoenix R/C Pro Simulator 3.0 with DX5e (RTM30R5510/RTM30R55101). DX6i/DX5e/DX4e:PID's beginning with one of the following prefixes: HS, HH, HT, HE, HA
DX8:PID's beginning with one of the following prefixes: HS, HH, HT, HE, HA, HO, HM, HR DX7:PID's beginning with the following prefix: HA JRP9503/JPR9309:PID's beginning with the following prefix: TM
We apologize for this inconvenience. Horizon disclaims all liability and warranties for any consumer failing to act upon this product bulletin. Always check your transmitter and equipment prior to each flight.
The 6-channel DX6i transmitter uses the same full-range DSMX® technology found in the Spektrum™ DX8 radio and includes an impressive list of programming features for both airplanes and helicopters that are simple to access and use. It comes with the AR6210 DSMX 6-channel receiver that is robust enough to use in large models yet compact enough to fit in many park flyers. The DX6i transmitter is also compatible with all existing Spektrum aircraft receivers. Whatever kind of flying you do, the DX6i transmitter can be adapted to most any model in your existing collection that requires six channels or less.
This DX6i package includes:1 transmitter 4 rechargeable AA batteries 1 charger 1 AR6210 6-channel DSMX receiver 1 manual/quick start guide
Neck strap is available separately.
Note: The DSMX DX6i is compatible with all current Spektrum DSM2® and DSMX aircraft receivers. The DSMX-branded DX6i transmitter is not compatible with the Spektrum AR6000/BR6000 receiver.
Always purchase products from a Horizon Hobby, Inc. authorized dealer to ensure authentic high-quality Spektrum product. Horizon Hobby, Inc. disclaims all support and warranty with regards, but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM2, DSMX or Spektrum.
Attention: Horizon Hobby has confirmed that all Spektrum Products being sold by KoKo Technology are counterfeit. We consider it a danger to use these products, waive all liability and will not support any warranty or service in regards to them.
Please follow the instructions in this tutoral to find your serial number - https://youtu.be/p8BcdsZd1eA
Please follow the instructions in this tutoral to learn how to register your Spektrum RC products- https://youtu.be/Bu7ObvRU-yo
Please follow the instructions in this tutoral to learn how to downloadn and install firmware updates for your Spektrum Radio- https://youtu.be/5VBGEbgS9pQ
Visit the product page on HorizonHobby.com for your transmitter and click on the "Manuals and Support" tab for downloadable setups.
Spektrum receivers are compatible with most popular speed controls and servos on the market.
DSM or Digital Spectrum Modulation is Spektrum's proprietary method of implementing 2.4GHz spread spectrum technology for the R/C industry. DSM divides the 2.4GHz band into 80 individual channels (frequencies) and incorporates direct sequence spread spectrum with an embedded GUID (Globally Unique Identifier) code. DSM has been painstakingly optimized by our engineers for RC surface and aircraft use, offering the most robust RF link in the industry.
DSM2 is the 2nd generation of Spektrum DSM technology and remains a premier 2.4GHz choice even today. Using the same superior wideband DSSS foundation that all Spektrum technology is based on, DSM2 consistently provides faster response and more precision than most non-DSM 2.4GHz protocols.
DSMX is a natural evolution of DSM2 technology that is the result of several years of development, optimized for pilots and combining Wideband DSSS and Frequency Agility. It builds on what has come before and takes DSM to the next level of robustness, reliability and efficiency without leaving current DSM2 users behind. DSMX represents the world's first wideband, frequency-agile 2.4GHz signal protocol and the most advanced spread spectrum RC technology to date.
These systems usually transmit a narrow band signal and rapidly jump through a fixed set of frequencies, spending a few milliseconds on each frequency.
The foundation DSMX is built on is the same foundation as DSM2™ - the superior on-channel interference resistance and coding gain of wideband DSSS. Compared to the wideband signal of a DSM2 or DSMX™ system, the narrow-band signal of other 2.4 transmitters is more likely to suffer crucial data loss in the event of on-channel interference. Think of wideband 2.4 as a river and narrow-band 2.4 as a stream. It takes much more interference to stop a river than it does to stop a stream.
The big reason wideband is so robust is coding gain. Essentially what this means is that the unique coding in a DSM2 or DSMX wideband signal allows it to be heard well above the noise of surrounding 2.4GHz signals without requiring any more power. In fact, a Spektrum wideband signal can achieve as much as 3X the range of its narrow-band competition using the same amount of power.
For the most part, yes. DSM2 transmitters are forward compatible with DSMX receivers and DSMX transmitters are backward compatible with DSM2 receivers. And because DSM2 and DSMX share the same wideband DSSS foundation, all Spektrum users will enjoy superior range, speed and precision whether they're using DSM2 equipment, DSMX equipment or a combination of both. The only exception is the DXe which is DSMX-only and not compatible with DSM2 receivers.
Yes, but DSM2 users who rarely, if ever, fly in big events or other "noisy" 2.4GHz environments may find the DSM2 equipment they have now is all they will ever need. The difference DSMX makes is only apparent when hundreds of 2.4GHz systems are in use at once. To see if your transmitter is eligible for the DSMX add-on, please visit horizonhobby.com, click on the “radios” tab, and select “DSMX addons” for more details.
A safety feature that prevents a pilot from flying a model when the model selected in the radio is not correct.
A resequencing of the data a Spektrum transmitter transmits based on the type of mixing you select. This feature helps to sync control services that are connected (such as a swash plate on a helicopter) and is used in radios that have many channels.
The Spektrum™ X-Plus™ 8 module lets you add 8 fully proportional channels to specially equipped Spektrum transmitters and receivers with 10 or more proportional channels. Just plug it into the X-Plus port of a compatible receiver. It is ideal for scale modelers who like to push realism to the extreme with working accessories and lights in addition to the regular control functions. The DX10t and DX18 offer X-Plus.
You should have no problem maintaining control as long as you maintain direct line-of-sight with your model. If you try to fly behind a group of trees or otherwise obstruct your direct line-of-sight, you could be susceptible to losing your control link.
You can download Spektrum Apps from the Google Play Store at https://play.google.com/store/apps/developer?id=Horizon+Hobby,+Inc. or from the iTunes store at https://itunes.apple.com/us/developer/horizon-hobby-inc/id415542050
The length of the antenna is on a Spektrum receiver is set and tuned to optimize the range and performance of the receiver. We do not recommend altering the length of the antenna on any Spektrum Receiver.
For help and assistance on your Spektrum products you can contact Horizon Hobby Product Support at https://www.horizonhobby.com/content/service-center-render-service-center, the Spektrum Facebook page at https://www.facebook.com/SpektrumRC/ pr the Horizon Hobby Facebook page at https://www.facebook.com/HorizonHobby/.
How to Setup your Spektrum DX6i to fly the E-flite X-Vert VTOL
Technical questions about this Spektrum product should be directed to Horizon Hobby's Product Support Department:
Horizon Hobby, LLC. ATTN: Product Support 4105 Fieldstone Road Champaign, IL 61822
To place a Horizon Hobby Support Inquiry please visit our Inquiry Form Support Phone:(877) 504-0233 Fax:(217) 355-1552
If you would like to purchase this product, please go to the Store Locator or contact the Horizon Hobby Consumer Sales Department:
Horizon Hobby, LLC. ATTN: Consumer Sales 4105 Fieldstone Road Champaign, IL 61822 Email: firstname.lastname@example.org Sales Phone:(800) 338-4639 Fax:(217) 355-1552
