Key Features

  • Based on the Scott Gray designed Vibe 90SG glow powered heli for flying styles from Extreme 3D to FAI Precision
  • Designed for 450 to 500kv electric motor running on 12S LiPo battery power
  • 10t, 11t, and 12t pinion gears included with conversion kit which allows you to select the proper gear ratio to match motor specs
  • Bottom mounted battery location which allows quick and easy battery changes

Needed To Complete

You will need the following: 3ea collective servos, 1ea tail rotor gyro and servo, receiver, and flight pack, brushless motor - 450 to 500Kv (see Specifications for details), HV Speed Control, 12S (2 x 6-cell) 3850 to 5000mAh LiPo batteries, Main rotor blades, Tail rotor blades, Flybar paddles

Overview

The Vibe™ 90SG E12 heli kit brings electric power to JR's most versatile heli the Vibe 90SG. Converting to electric power brings the benefits of reduced fuel cost, vibration less operation and an improvement in overall performance. With a linear throttle and instant power it's hard to beat the Vibe 90SG E12 for 3D and F3C flying.

Assembly Time: 20+ Hours
Completion Level: Kit
Control System: CCPM 120 or 140
Flying Weight: 9.9–10.3 lb (4.50–4.70 kg)
Is Assembly Required: Yes
Main Gear Ratio: T10 Pinion Gear 9.6:1, 11T Pinion Gear 8.73:1, 12T Pinion Gear 8:1
Main Motor Size: 450 to 500Kv, Diameter - 70mm (max), Length - 67mm (max), Shaft Diameter - 6mm, Mounting Screw Spacing 4mm, Mounting Screw Pitch 30~32mm
Main Rotor Diameter: 63 in (1600mm)
Recommended Environment: Outdoor
Rotor Type: Collective Pitch Single Rotor
Size/Scale: 700
Tail Rotor Diameter: 11.34 in (288mm)
