This item is no longer available, however we may have replaced them with newer versions. Please follow the link below to see the related product.
| Application: | Airplane |
|---|---|
| Benchmark Prop: | 11x7 @ 13000 rpm |
| Bore: | .94 in |
| Carb Type: | Barrel with two needles |
| Crank Type: | Ball Bearing |
| Crankshaft Threads: | 5/16x24 |
| Cylinder Type: | ABC |
| Cylinders: | Single |
| Displacement: | .61 cu. in. (10.0 cc) |
| Engine (Only) Weight: | 20.32 oz |
| Fuel: | 10 - 30 pct Nitro |
| Fuel Type: | Glow |
| Mounting Dimensions: | 55mm x 25mm |
| Muffler Type: | Cast |
| Muffler Weight: | 5.12 oz |
| Prop Range: | 11x7 - 12x6 |
| RPM Range: | 2000 to 13000 |
| Stroke: | .86 in |
| Total Weight: | 25.44 oz |
| Type: | 2-stroke |
Here are some articles we think will be of interest to you as you consider Horizon Hobby products. We'll add new relevant articles as they become available.
It has come to our attention that the part number for the Evolution 61 needle valve assembly in the Evoluiton Engines instruction manual is incorrect. The correct part number is EVO061874. Please make this note in your manual for future reference.
