Image for Fuze 1 10 4 pole 3000Kv ESC Motor Combo from HorizonHobby
+ / - Hover over image to Zoom
Share
Email a Friend

Key Features

  • 4-Pole design for increased torque and improved overall efficiency
  • Sensorless brushless technology for improved performance and maintenance free operation
  • Standard 1/8 in shaft
  • 3.5mm bullet style connectors
  • Available in 3 different KV ratings including 2800kv, 3300kv and 4000kv
  • Waterproof ESC
  • Pre-wired with high-current EC3 connector and 3.5mm bullet style connectors
  • NiMH and Li-Po compatible
  • 45A can handle 4‐9 cell NiMH or 2S‐3S Li‐Po
  • Built in Cooling fan
  • Easily programmable through integrated setup button
  • Compact design for easy fit into most any 1/10th scale on and off road platform

Overview

Dynamite’s Tazer brushless systems offer price sensitive enthusiasts the ultimate solution when searching for an easy and affordable method of stepping up to brushless power. Designed for most 1/10th scale on and off road electric vehicles, each system comes with everything users need to upgrade to brushless power. All systems include a potent 4-pole sensorless brushless motor and 45A waterproof ESC that comes pre-wired with a high-current EC3 connector. The
ESC is Ni-MH and Li-Po/Li-Fe compatible and was designed to handle up to a 9 cell Ni-MH pack or 3S Li-Po/Li-Fe. And, as with all Dynamite power systems, motors and ESC’s are available separately.

Dynamite’s Tazer brushless systems are compatible with most 1/10th scale on and off‐road electric vehicles including 1/10th scale ECX, Losi, HPI, Traxxas, Associated and many more.

Drive Type: Forward/Reverse
Input Connector Types: EC3
Motor Limit: 2S LiPo - up to 6000KV On-Road/4000KV Off-Road. 3S LiPo - up to 4000KV On-road/2500KV Off-road
Motor Type: Brushless - Sensorless
Programmable: Yes
Shaft Diameter: 1/8 in (3.175mm)
Shaft Length: 0.59 in (15mm)
Speed Control Type: Brushless - Sensorless
